5-22
5-3 I/O Signal Setting
- SV Series User’s Manual -
COMMON PARAMETER SETTING
Input Auto ON Setting
Specific terminal functions of the pulse/analog input type servo amplifier can be set to auto ON, independent of input
status of the I/O terminals. Auto ON setting can be set through a parameter.
When servo ON is set to "AutoON", motor will start to operate once main circuit power is powered ON. Safety
measures must be taken, since unexpected operation of servo motor and mechanical system may occur.
Signal name Parameter type Setting range Default Enable timing
SVON IO_24
0:
Disable
1: AutoON
0
After power is ON
again
ST1 IO_25 0
ST2 IO_26 0
RS1 IO_27 0
RS2 IO_28 0
