9-1 Servo Trial Run
SERVO TRIAL RUN FUNCTION
- SV Series User’s Manual -
How to execute servo JOG operation
z
Execute with Access Window
1 Press "i " to display the main menu.
2 Press " "/" ", select "5.SrvTestRun", then press the " " to
display the submenu.
3 Press " "/" " to select "1.ServoJOG", then press the " ".
4 Press " "/" " to select "Parameter", then press " ".
5 Press and hold the " " key (for more than 1s) to until the value flickers.
6 Press and hold the " " key (for more than 1s) to change the value. Repeat the above steps to set up other
parameters.
7 Press " " key to go back to the menu of step 3.
8 Press " "/" " to select "Execute", then press " ".
9 Press " "/" " key to execute JOG operation after servo ON.
To stop the operation, release all keys and press " ".
Execute with KV-ML/MC setting tool (KV MOTION+)/SV series setting software
For operating method with KV-ML/MC setting tool (KV MOTION+)/SV series setting software, see the following
manuals.
KV-ML/MC Setting Tool User's Manual, Chapter 7 "SV Monitor"
SV series Setting Software User's Manual, Chapter 6 "SV Monitor"
5.SrvTestRun
6.SetDisplay
7.ML Com
8.Other
1.ServoJOG
2.PTN Move
3.Org Search
Parameter
Execute
VEL_02
SpdAccelTime
(ms)
0
Parameter
Execute
JOG Speed
+ -
(min-1)
0
To Next Page
