8-13
8-3 Switching to Manual Tuning
TUNING
- SV Series User’s Manual -
10 "running…" is displayed
The estimation of ratio of inertia moment is executed.
The servo motor may operate automatically. Ensure to do this safely.
11 When estimation of ratio of inertia moment is completed, "Done" is displayed on the screen.
Press " " to display the main menu.
12 The result of ratio of inertia moment is dispayed.
If the estimation result is correct, press and hold " " key (for more than 1 s).
13 The result is mapped to moment of inertia ratio of servo parameter when
"Done" is displayed on the screen. Now the operation is completed.
■ Execute with the KV-ML/MC setting tool (KV MOTION+)/SV series setting software
For how to operate KV-ML/MC setting tool (KV MOTION+)/SV series setting software, see the following manuals.
KV-ML/MC Setting Tool User's Manual, Chapter 7 "SV Monitor"
SV series Setting Software User's Manual, Chapter 6 "SV Monitor"
Tuning
ClcInertia
running…
Tuning
ClcInertia
Done
Tuning
Reflect OK?
100(%)
Done
To Next Page
