8-17
8-4 Gain Search PRO
TUNING
- SV Series User’s Manual -
6 Press " "/" "to select "Condition". Then press " ".
7 "Distance" screen is diaplayed when executing Gain search PRO (w/o higher-level command) ,
You need set up the "distance" from this window. When Gain search PRO (w/ higher-level command) is selected, the
"Travel distance" is unavailable.
8 Press " "/" " key to select your desired "Tuning type".
9 Press " "/" " key to select you desired "Filter type".
10 Press " " key to display the submenu.
11 Press " "/" " to select "Execute". Then press " ".
12 Press and hold the key (for more than 1s). When "Execute" is flickering,
press and hold the " " key (for more than 1s) again.
* For servo ON, Gain search PRO (w/o higher-level command) cannot be executed.
Be sure to execute in servo OFF status.
13 The "running..." message is displayed.
Gain search PRO is displayed.
When Gain search PRO
(w/o higher-level command) is selected, the servo motor may move automtically.
Ensure safety.
When Gain search PRO (w/ higher-level command) is selected, the servo is ON and commands are received from higher-
level positioning/motion unit.
14
When Gain search PRO is completed. The "Done" message is displayed.
Press " ".
15 The "Reflect OK?" screen is displayed.
Press and hold the " "key (for more than 1s).
16 When mapping is completed, the "Done" message is displayed.
Now the operation is completed.
■ Use the KV-ML/MC setting tool (KV MOTION+)/SV series setting software
For how to operate KV-ML/MC setting tool (KV MOTION+)/SV series setting software, see the following manuals.
KV-ML/MC Setting Tool User's Manual, Chapter 7 "SV Monitor"
SV series Setting Software User's Manual, Chapter 6 "SV Monitor"
Tuning
Distance
(CMD_PLS)
+3145000
Tuning
Tuning Type
Low
Tuning
Filter Type
Ball Screw
Parameter
Condition
Execute
Tuning
GainSrchIN
Execute
Tuning
GainSrchIN
running…
Tuning
GainSrchIN
Done
Tuning
Reflect OK?
Tuning
Reflect OK?
Done
