1-2 SV Series Model
BEFORE USING
- SV Series User’s Manual -
Cable
Motor power cable
(For 1kW/1.5kW)
Standard cable
SV-C3D Cable length 3m
SV-C5D Cable length 5m
SV-C10D Cable length 10m
SV-C20D Cable length 20m
Motor power cable
(For 2kW)
Standard cable
SV-C3E Cable length 3m
SV-C5E Cable length 5m
SV-C10E Cable length 10m
SV-C20E Cable length 20m
Motor power cable
(For 3kW/5kW)
Standard cable
SV-C3F Cable length 3m
SV-C5F Cable length 5m
SV-C10F Cable length 10m
SV-C20F Cable length 20m
Electromagnetic brake power
cable
(For 1kW to 5kW)
Standard cable
SV-D3D Cable length 3m
SV-D5D Cable length 5m
SV-D10D Cable length 10m
SV-D20D Cable length 20m
MECHATROLINK-II
MECHATROLINK-II cable
SV-LA5 Cable length 0.5m
SV-L1 Cable length 1m
SV-L3 Cable length 3m
SV-L5 Cable length 5m
SV-L10 Cable length 10m
SV-L20 Cable length 20m
MECHATROLINK-II terminator SV-LT1
Ferritic core OP-84409
For MECHATROLINK-II
cables
Components for I/O
connection of
servo amplifier
(ML-II : 26 pin
PLS : 50 pin)
I/O connector cable
26pin
OP-84402
Cable length 1m, single-end
barbed wire
OP-84403
Cable length 3m, single-end
barbed wire
50pin
OP-84400
Cable length 1m, single-end
barbed wire
OP-84401
Cable length 3m, single-end
barbed wire
Terminal block cable for I/O
connector
26 pin KV-HC3 Cable length 1m
50 pin KV-HC4 Cable length 1m
I/O connector
26 pin OP-84407
50 pin OP-51419
Terminal block for I/O connector
26 pin OP-84411
50 pin OP-84410
KV-MC40V/MC20V/H40S/H20S/H20G
Connector adaptor unit with terminal block
KV-HTC8
Board module KV-HM8
Other servo amplifiers
Regenerative resistor
OP-84399 Support 50Ω, 50W to 1kW
OP-87073 Support 20Ω, 1.5kW
*1
Analog monitor cable OP-84408 Cable length 1m
Lithium battery with battery case SV-B1
SV-B1 extention cable OP-87074
For 2kW to 5kW, SV-B1 may
be used
Branch cable for battery connecting OP-84398 Cable length 0.35m
Lithium battery option OP-51422
Connector set for encoder /motor
power supply
For 50W/100W OP-84404
For 200W/400W OP-84405
For 750W OP-84406
Connector set for encoder
For 1kW to 5kW
OP-87066 Angle connector
OP-87065 Straight connector
*1 2kW to 5kW can also be used depending on operational conditions. "5-4 Regenerative Resistor Setting",
page 5-23.
