2-8
2-3 Servo Amplifier Specifications
- SV Series User’s Manual -
CONFIGURATION & SPECIFICATIONS
Item Specifications
Model SV-1002SV-1502 SV-2002 SV-3002 SV-5002
Capacity 1.0kW 1.5kW 2.0kW 3.0kW 5.0kW
Input power supply
Voltage/frequency
Main circuit 3-phase, 200 to 230 VAC, 50/60 Hz, 270 to 320 VDC
Control circuit Single-phase, 200 to 230 VAC, 50/60 Hz
Allowable voltage
fluctuation
Main circuit/
Control circuit
170 to 253 VAC
Allowable
frequency
fluctuation
Main circuit/
Control circuit
±5% max.
Allowable
momentary power
failure
Main circuit Full (100% down): 0.5 cycle, Partial (50% down): 1 cycle
Control circuit Approx. 100 ms
Overvoltage category III
Control system
3-phase full-wave rectification, IGBT PWM control, sinusoidal current drive
system
Feedback 20-bit serial encoder (incremental/absolute) transmission
Environment
Operating ambient temperature 0 to +55°C (No freezing)
Storage ambient temperature -20 to +70°C (No freezing)
Operating/storage ambient humidity 90% RH max. (No condensation)
Resistance to vibration 4.9m/s
2
(Complies to JIS C60068-2-6)
Shock resistance 19.6m/s
2
(Complies to JIS C60068-2-27)
Operating atmosphere (Enclosure
rating, Pollution degree)
Pollution degree: 2 (Inside the industrial control panel with IP54 or higher)
- No corrosive or flammable gas.
- Do not splash water, oil, or chemicals onto the unit.
- No dust in the operation area.
Altitude 1,000 m max. above sea level
Applicable
standard
UL/CSA Standard UL508C, CSA C22.2 No.14
CE Marking
Low-voltage
Directive
EN50178
EMI EN55011 Class A, EN61800-3
EMS EN61800-3, EN61000-6-2
North American EMI Regulation FCC Part15 B, ICES-003. Class A
Structure
Installation Base mount
Protection Open, forced cooling
Minimum insulation resistance 1 MΩ min. with 500 VDC megohmmeter
Insulation withstand voltage
1500 VAC min. (between primary side and ground)
1800 VAC min. (between primary side and secondary side)
Weight Approx. 1.5kg Approx. 2.4kg Approx. 2.9kg Approx. 2.9kg Approx. 4.7kg
