4 Transport, installation and commissioning
Installation
MB-20-G/MB-200G-W_MB-LABmaster_MB-200 MOD_TP700
Operating Manual - V5.0 - 04/2018 - STD
Page
4 - 17
Flow rate 250 l/min
Connection type Ø 10 mm cutting ring screw
Inlet (1a)
Connection equipment provided by the operating company: supply piping for working gas.
Use Connecting the working gas source to the working gas inlet
Material Length as required
Ø 10 mm: either copper pipe, stainless steel pipe ore hose
Connection type Ø 10 mm cutting ring screw
Regeneration gas (3a/3b)
Overview
Use Regenerating the exhausted H
2
O/O
2
purifier columns
Gas type ¡ If nitrogen is used as working gas: nitrogen/Hydrogen mix-
ture (90-95% N2 with a 5…10% H
2
- portion)
¡ If helium is used as the working gas: helium/hydrogen mix-
ture (90-95% He with a 5…10% H
2
- portion)
¡ If argon is used as the working gas: argon/hydrogen mixture
(90-95% Ar with a 5…10% H
2
- portion)
Purity Medium Purity (4.8 or higher); from bottles or other gas supply
equipment
Quantity Approx. 3.5 m
3
per each regeneration
NOTICE
A hydrogen concentration in the regeneration gas of ≥ 10% will cause the reactor
to overheat
Property damage
► Make sure that the hydrogen concentration in the regeneration gas remains always ≤
10%
