Midas XL8

186 Chapter 9: Basic Operation
XL8 Control Centre
Operator Manual
5
6
7
8
Illuminated aux numbers
indicate that this is the
selected pair
Ramp shows that this
signal is post-fader
Bar shows that this
signal is pre-fader
This transition point, where solid colours
change to translucent, indicates 0dB
across the eight auxes
Level indicators are
bright on selected
channel but dimmed on
inactive/muted channels
Matrix mix
Aux mix
