Chapter 3 Maintenance Mode Functions and Operations
3-70
(4) PRIME 1 INK COLOR
Note
Before performing this procedure, open the COVER(CENTER)-F and remove the
COVER(R)ASSY-MW (see 6.3.2).
If you start the procedure before removing the COVER(R)ASSY-MW, you will have to performed
the procedure again with the COVER(R)ASSY-MW removed after finishing it once by opening the
COVER(CENTER)-F.
Select PRIME 1 INK COLOR with the Up and Down buttons, and then press the OK button.
Move the cursor with the Right and Left buttons, and toggle a digit with the Up and Down
buttons.
A digit that has been toggled disappears.
Finish the selection and press the OK button.
Note
Do not select numbers of tubes that have not
been replaced as the pumps will run
unecessarily and ink will be wasted.
Install the jigs SINGLE COLOR FILLING TOOL(MV) for the selected colors and press the OK button.
(See 6.8.1 for how to use the SINGLE COLOR FILLING TOOL(MV).)
Check that a waste ink bottle is installed and press the OK button.
Press the OK button after you have installed the jigs.
Press the OK button and open the ink box cover.
INSTALL XXXXXXX
INK SUCTION TOOL ◎
>>PRIME 1 INK COLOR
BOTTLE IS EMPTY? ◎
>>PRIME 1 INK COLOR
PRINT HEAD : 1 3 ◎
>>PRIME 1 INK COLOR
PRINT HEAD : 1234567 ◎
>PH MAINTENANCE
PRIME 1 INK COLOR ◎
To Next Page
