OKI Data Infotech Corporation CONFIDENTIAL
Chapter 3 Maintenance Mode Functions and Operations
3-71
The following message is displayed when the ink cartridges are installed to the main tank. In this
case, close the ink box cover.
* If the ink cartridges are not installed, install them.
Press the OK button to start priming the system.
The pump stops running.
Remove the jig SINGLE COLOR FILLING TOOL(MV) and press the OK button.
Check that a waste ink bottle is installed and press the OK button.
A normal cleaning is performed.
CLOSE INK BOX COVER
OPEN INK BOX COVER
PH RECOVERING XXXXXXX
REQUIRED TIME Y:YY
START PH RECOVERY
BOTTLE IS EMPTY? ◎
REMOVE
INK SUCTION TOOL ◎
START FILLING
BOTTLE IS EMPTY? ◎
