OKI Data Infotech Corporation CONFIDENTIAL
Chapter 3 Maintenance Mode Functions and Operations
3-72
(5) PRIME 1 PRINT HEAD
This procedure is used to remove air accumulated in the tubes.
Note
Before performing this procedure, open the COVER(CENTER)-F and remove the
COVER(R)ASSY-MW (see 6.3.2).
If you start the procedure before removing the COVER(R)ASSY-MW, you will have to performed
the procedure again with the COVER(R)ASSY-MW removed after finishing it once by opening the
COVER(CENTER)-F.
Select PRIME 1 PRINT HEAD with the Up and Down buttons, and then press the OK button.
Move the cursor with the Right and Left buttons, and toggle a digit with the Up and Down
buttons.
A digit that has been toggled disappears.
Finish the selection and press the OK button.
Install the jig SINGLE COLOR FILLING TOOL(MV) and press the OK button.
(See 6.8.1 for how to use the SINGLE COLOR FILLING TOOL(MV).)
Check that a waste ink bottle is installed and press the OK button.
Press the OK button after you have installed the jig.
Press the OK button and open the ink box cover.
INSTALL XXXXXXX
INK SUCTION TOOL ◎
>>PRIME 1 PRINT HEAD
BOTTLE IS EMPTY? ◎
>>PRIME 1 PRINT HEAD
PRINT HEAD : 1 3 ◎
>>PRIME 1 PRINT HEAD
PRINT HEAD : 1234567 ◎
>PH MAINTENANCE
PRIME 1 PRINT HEAD ◎
To Next Page
