Chapter 3 Maintenance Mode Functions and Operations
3-73
The following message is displayed when the ink cartridges are installed to the main tank. In this
case, close the ink box cover.
* If the ink cartridges are not installed, install them.
Press the OK button.
The pump stops running.
Note
Again check that the print heads and the jig
SINGLE COLOR FILLING TOOL(MV) are
correct.
Remove the jig SINGLE COLOR FILLING TOOL(MV) and press the OK button.
Check that a waste ink bottle is installed and press the OK button.
A normal cleaning is performed.
PH RECOVERING XXXXXXX
REQUIRED TIME Y:YY
START PH RECOVERY
BOTTLE IS EMPTY? â—Ž
REMOVE
INK SUCTION TOOL â—Ž
FILLING WITH LIQUID
TIME REQUIRED Y:YY
START PRIMING PH?
OK? â—Ž
To Next Page
