Chapter 5 Troubleshooting (Engine Section and USB Controller Section)
5-39
<Description>
With the skew check after the media installation, 100-mm media was fed, and, the media edge
was misaligned by ±2 mm or more.
<Action>
Re-install the media.
If the error persists after re-installing the media, check the Items to be Checked on the table
below,, and perform the actions starting from the top until the problem is solved.
No
Items to be Checked
Action
1
Media surface condition
The media edge may not be detected when the
condition is as follows.
- Black-surface media; or
- Matte media.
Try another media.
2
Non-reflecting tape condition on
the platen
Check that the tape is not smeared. If it is, softly wipe
it with a soft cloth or lint-free paper dampened with
wiper cleaning liquid or cap cleaning liquid.
3
SENSOR(EDGE)MAINTENANCE
Check that the harness connector is securely
connected to the board’s connector.
Remove the sensor, softly wipe it with a soft cloth or
lint-free paper dampened with ethanol, and
re-connect it.
If the error persists, replace the sensor.
<Description>
It has been detected that the media edges are misaligned by 3 mm or more due to a media skew.
<Action>
Reinstall the media.
If the problem is not solved even after reinstalling the media, perform the same actions as with
MEDIA HAS SKEWED ALIGN MEDIA.
MEDIA HAS SKEWED
ALIGN MEDIA
MEDIA HAS SKEWED
ALIGN MEDIA
