OKI Data Infotech Corporation CONFIDENTIAL
Chapter 7 Adjustment
7-21
When the edges of the wiper central part are not aligned with the wiping position adjustment pin,
adjust their positions using the button as follows.
- Press the Left button once to move the carriage approximately 0.1 mm to the left.
- Press the Right button once to move the carriage approximately 0.1 mm to the right.
9. When the wiping position is correct,
press the OK button.
The wiping position adjustment value is
changed.
*Remove the wiping position adjustment pin and return it to its original location.
10. After moving the wiper blade to its home
position, move the carriage to its home
position.
<Note>
Follow the procedure below to check or enter the wiping position adjustment value.
(Display at the end of the wiping unit
position adjustment.)
1. With the Up and Down buttons, select
WIPER U ADJUST VAL, then press the
OK button.
2. The current wiper unit adjustment value
is displayed.
CARRIAGE IS MOVING
PLEASE WAIT
REMOVE THE WIPING
POS ADJUST PIN OK? ◎
>>WIPING POS ADJUST
↕ ADJUST WIPER UNIT ◎
>>WIPING POS ADJUST
 ADJUST WIPER UNIT ◎
>>>WIPER U ADJUST VAL
 ±X.X  ±Y.Ymm ◎
>>WIPING POS ADJUST
 WIPER U ADJUST VAL ◎
