Chapter 7 Adjustment
7-20
8. Press the OK button.
Then use the Left and Right buttons to
adjust the wiping position.
You may press the CANCEL button to
display the message in step 9 REMOVE
THE WIPING POS ADJUST PIN and
terminate the adjustment operation (see
step 9 below).
Adjust the wiping position using the Left
and Right buttons.
Note
Check the position of the wiper blade and wiping position adjustment pin with standing at the
position where the wiping position adjustment pin is aligned with the extremity of the screw in the
front.
ADJ POS W/ R&L KEYS
OK/CANCEL â—Ž
The edge of the wiper central part cannot be seen on
one side of the pin.
Adjust the position so that both edges of the wiper
central part can be seen on the right and left of the
adjustment pin.
To Next Page
