Chapter 7 Adjustment
7-32
4. Remove the reservoir.
5. Remove the STOPPER-PLT with two
screws.
6. Install the STOPPER-PLT so that the
bent part of the TRAY-BU comes above
the bent part on the STOPPER-PLT.
TRAY-BU
STOPPER-PLT
TRAY-BU
STOPPER-PLT
