Chapter 7 Adjustment
7-33
7. Rotate the cog wheel of the REMAINING
INK SENSOR to the clockwise direction
until it stops.
8. Install the REMAINING INK SENSOR
with two screws.
9. Remove the STOPPER-PLT with two
screws.
10. Install the STOPPER-PLT so that the
bent part of the TRAY-BU comes below
the bent part on the STOPPER-PLT
(normal configuration).
To Next Page
