Chapter 7 Adjustment
7-34
11. Place the WEIGHT(1000) on the
TRAY-BU, and push the TRAY-BU
downward with still the weight on it.
12. When you have pushed the TRAY-BU
down to the stopper position, release the
pressure in one go.
13. Slide the BASE-BOTTLE-BU-ASSY to
the front to place it in its normal position.
14. Secure the BASE-BOTTLE-BU with
three screws.
To Next Page
