Chapter 3 Maintenance Mode Functions and Operations
3-59
(5) EDGE SENSOR ADJUST (displayed in maintenance mode only)
This menu is used to print the edge sensor position adjustment pattern and to set adjustment
values for the edge sensor and top and side positions.
(a) PRINT PATTERN
Select EDGE SENSOR ADJUST with the Up and Down buttons, and then press the OK button.
Select PRINT PATTERN with the Up and Down buttons, and then press the OK button.
Press the OK button to display the print confirmation screen, then press the OK button again to
start printing.
Press the OK button to start printing.
You may press the CANCEL button to interrupt the printing.
>>EDGE SENSOR ADJUST
EXECUTING...
>>EDGE SENSOR ADJUST
EXECUTE OK? ◎
>>EDGE SENSOR ADJUST
PRINT PATTERN ◎
>MECHANICAL ADJUST
EDGE SENSOR ADJUST ◎
To Next Page
