Ricoh Aficio SP C232SF User Manual

Maintenance
312
10
R
CAUTION:
A Pull up the lever on the top cover, and then carefully raise the top cover.
Make sure that the exposure glass cover or ADF is closed.
B Lift out the rearmost print cartridge.
C Slide the toner density sensor lever once to the left.
Slide the lever only once.
• The inside of this machine becomes very hot. Do not touch the parts la-
belled “v” (indicating a hot surface).
BPC042S
BAA078S
BAA079S

Ricoh Aficio SP C232SF Specifications

General

Brand	Ricoh
Model	Aficio SP C232SF
Category	All in One Printer
Language	English
