Getting Started
84
2
Loading Paper in the Optional Paper Feed Unit
The following example explains the loading procedure for the optional paper
feed unit.
A Lift and pull the optional paper feed unit, and then hold the tray with both
hands, and then pull it out.
Place the tray on a flat surface.
B Press down on the bottom plate until it clicks.
C Pinch the clips on the side paper guide, and then adjust the guide to the pa-
per size.
BAA043S
ASH077S
ASH078S
