Jitter (ms)—Variance (in milliseconds) occurring in the reference
input time (from one poll to the next).
Jitter—This is a graphical representation of the system jitter over
time. Clicking on this graph in the NTP Status Summary panel will
open a window in the main panel containing a larger, more detailed
view of the graph. See "The NTP Jitter Performance Graph" on
page321.
Note: This panel is updated every 30 seconds, or upon clicking
the browser refresh button.
The NTP Time Offset Performance Graph
To view the NTP Time Offset performance graph:
1.
Navigate to MANAGEMENT > NETWORK: NTP Setup.
2.
In the NTP Status Summary panel locate the Time Offset graph.
4.5 Quality Management
CHAPTER 4 • SecureSync 2400 User Manual Rev. 5.2
319
