Card
ID*
Card Name Name in UI See ...
17 Square Wave (TTL) output
module
Sq Wv Out, BNC
"Programmable Square Wave
Out [1204-17]" on page411
18 Quad 1 PPS output module
(TTL)
1PPS Out BNC
"1PPS Out [1204-18, -19, -21, -
2B]" on page386
19 Quad 1 PPS output module
(10 V)
1PPS Out 10V
"1PPS Out [1204-18, -19, -21, -
2B]" on page386
1B HaveQuick output module
(RS-485)
HAVEQUICK Out,
RS-485
"HAVE QUICK Out [1204-10, -
1B]" on page470
1C 10 MHz output module (3
outputs)
10 MHz Out
"Frequency Out [1204-08, -1C,
-26]" on page403
1D STANAG input module STANAG In
"STANAG In [1204-1D, -24]"
on page462
1E IRIG module, Fiber Optic (4
outputs)
IRIGOut, Fiber
"IRIG Out [1204-15, -1E, -22]"
on page432
1F NENA Card NENA
"NENA-Compliant Option
Card [-1F]" on page532
21 Quad 1 PPS output module
(RS-485 [terminal block])
1PPS Out, RS-485
"1PPS Out [1204-18, -19, -21, -
2B]" on page386
22 IRIG module, RS-485 (4 out-
puts)
IRIG Out, RS-485
"IRIG Out [1204-15, -1E, -22]"
on page432
23 Event Broadcast module Event Broadcast
"Event Broadcast [1204-23]"
on page545
24 STANAG isolated input
module
STANAG In, Isol-
ated
"STANAG In [1204-1D, -24]"
on page462
25 STANAG isolated output
module
STANAG Out, Isol-
ated
"STANAG Out [1204-11, -25]"
on page454
26 1 MHz output module (3
outputs)
1MHz Out
"Frequency Out [1204-08, -1C,
-26]" on page403
27 IRIG module, Fiber Optic (1
input, 2 outputs)
IRIG In/Out, Fiber
"IRIG In/Out [1204-05, -27]"
on page438
28 1-in/3-out 1 PPS module
(TTL [BNC])
1PPS/Frequency
RS-485
"1PPS In/Out [1204-28, -2A]"
on page391
29 1-in/3-out HaveQuick mod-
ule (TTL [BNC])
HAVEQUICK
"HAVE QUICK In/Out [1204-
29]" on page476
2A 1-in/3-out 1 PPS module
(Fiber Optic)
1PPS In/Out, Fiber
"1PPS In/Out [1204-28, -2A]"
on page391
2B Quad 1 PPS output module
(Fiber Optic)
1PPS Out, Fiber
"1PPS Out [1204-18, -19, -21, -
2B]" on page386
2E Revertive Selector module
("Failover")
n/a
"Revertive Selector Card
[1204-2E]" on page543
22
CHAPTER 1 • SecureSync 2400 User Manual Rev. 5.2
1.5 Option Cards
