Disabled
CTCSS 1/3 Tones
CTCSS 1/10 Tones
Data Clocks
1PPS
Signal Output:
CTCSS 1/3 Tones (see also: "CTCSS exact (1/3 Hz) tones" on
page422)
CTCSS 1/10 Tones (see also: "CTCSS exact (1/10 Hz) tones" on
page423)
Data Clocks (see also: "Data Clock Signals" on page423)
1PPS (see also: "1PPS Duty Cycle" on page423)
Offset: Value in nanoseconds that can be used to adjust for cable delays or
latencies.
Signature Control: Controls when the output will be present. For more
information, see "Signature Control" on page183.
819x Option 17 Mapping
To replicate settings used in Series 819x devices, use the following information to
configure option card no. 1204-14 for compatible CTCSS operation:
DB-9 Output Index 0: Set to desired CTCSS 1/10 or CTCSS 1/3 tone
DB-9 Output Index 1: Set to 18 kHz Data Clock
DB-9 Output Index 2: Set to desired CTCSS 1/10 or CTCSS 1/3 tone.
Alarm Outputs: Edit Window
To configure one of the ALARM Outputs, go to its Edit window. For instructions,
see: "Configuring Option Card Inputs/Outputs" on page364.
The Web UI list entry for this card is named: Simulcast.
