Note: Alarm Output 0 through Alarm Output 3 are reserved by
SecureSync. Numbering for alarm outputs from the option card will
begin at Alarm 4, which is available on the DB-9 output, while Alarms
5 and 6 are assigned to the RJ-12 connector.
Figure 5-33: Simulcast Alarm Output Status window
CTCSS Outputs: Edit Window
To configure a CTCSS output, go to its Edit window. For instructions, see: "Con-
figuring Option Card Inputs/Outputs" on page364.
The Web UI list entry for this card is named: Simulcast.
The Edit window allows the configuration of the following settings:
Signal Type: Allows selection of the desired signal type. Available options
include:
SecureSync 2400 User Manual 419
APPENDIX
