Format 3: Selects the third consecutive format message to be out-
putted. Select “None” if only one output format is desired. “None” will
be the only choice available if Format 2 is “None.”
Signature Control: Signature Control controls when the selected ASCII
data output format will be present;see "Signature Control" on page183.
Output Mode: This field determines when the output data will be provided.
The available Mode selections are as follows:
Broadcast: The format messages are automatically sent out on
authorized condition (Signature control), every second a message is
generated in sync with the 1PPS.
Request (On-time): A format message is generated in sync with 1PPS
after the configured request character has been received.
Request (Immediate): A format message is generated as soon as the
request character is received. As this selection does not correlate the
output data to the on-time point for the message, in Data Formats
that do not provide sub-second information (such as Formats 0 and 1
whereas Format 2 provides sub-second information), it should be
noted that the output data can be provided immediately, but a time
error could occur when using the on-time point of the message in
addition to the data for timing applications.
Note: The choices available in this field are determined by
the choices of Format Group and Format.
Time Scale: Used to select the time base for the incoming data. The
entered Timescale is used by the system to convert the time in the incom-
ing data stream to UTC time for use by the System Time. The available
choices are:
UTC: Coordinated Universal Time ("temps universel coordonné"), also
referred to as ZULU time
TAI: Temps Atomique International
GPS: The raw GPS time as transmitted by the GNSS satellites (as of
22-August-2023, this is currently 18 seconds ahead of UTC time).
492 SecureSync 2400 User Manual
APPENDIX
