5.
Confirm that Unicast Sync is checked. The 1204-32 PTP module should
always respond to unicast negotiations.
Configuring PTP on the Network
To configure PTP on the network:
1.
In the GB PTP Edit window, navigate to the Main tab.
2.
Under the Main tab of the GB PTP Edit window, make the following set-
tings:
Domain Number: Sets the current PTP Domain Number, as defined in
IEEE Std 1588-2008 Section 7.1
Clock Mode: See under "Main tab settings" on page502.
Enable DHCP: This is a checkbox to enable or disable the delivery of
IP addresses from a DHCP Server. The default setting is enabled (the
box is checked).
Static IP Address: When a DHCP server is not requested or is reques-
ted but not available, the PTP Module will use this IP address. In the
format “#.#.#.#” with no leading zeroes or spaces, where each ‘#’ is a
decimal integer from the range [0,255].
Network Mask: When a DHCP server is not requested or is requested
but not available, the PTP Module will use this Network Mask. In the
format “#.#.#.#” with no leading zeroes or spaces, where each ‘#’ is a
decimal integer from the range [0,255].
Default Gateway: When a DHCP server is not requested or is reques-
ted but not available, the PTP Module will use this Default Gateway. In
the format “#.#.#.#” with no leading zeroes or spaces, where each ‘#’
is a decimal integer from the range [0,255].
Configuring PTP Contracts
516 SecureSync 2400 User Manual
APPENDIX
