Note: If you have only one input or output of any type, NetClock will
number that input or output 0. Additional inputs or outputs will be
numbered 1 or above.
The IRIGoutput Edit window offers the following configuration fields:
Signature Control: Used to control when the IRIG modulation will be
present. This function allows the modulation to stop under certain
conditions;see also "Signature Control" on page183.
Format: Defines the desired IRIG output formatting. Available options
include: IRIG A, B, G, NASA-36, IRIG E (100Hz or 1kHz)
Modulation: Changes the type of output signal modulation:
IRIG AM is an amplitude modulated output. The amplitude of the out-
put is determined by the value entered in the “Amplitude” field.
IRIG DCLS is a TTL modulated output.
SecureSync 2400 User Manual 537
APPENDIX
