2 Parameters
2.1 Overview of parameters
SINAMICS G120 Control Units CU240B-2/CU240E-2
18 List Manual (LH11), 01/2016, A5E33839529
Scaling
Specification of the reference variable with which a signal value is automatically converted for
a BICO interconnection.
The following reference variables are available:
• p2000 … p2007: Reference speed, reference voltage, etc.
• PERCENT: 1.0 = 100 %
• 4000H: 4000 hex = 100 % (wort) or 4000 0000 hex = 100 % (double word)
• p0514: specific normalization
Refer to the description for p0514[0…9] and p0515[0…19] to p0524[0…19]
Dyn. index (dynamic index)
For parameters with a dynamic index [0...n], the following information is specified here:
• Data set (if available).
• Parameter for the number of indices (n = number - 1).
The following information can be contained in this field:
• "CDS, p0170" (Command Data Set, CDS count)
Example:
p1070[0] main setpoint [command data set 0]
p1070[1] main setpoint [command data set 1], etc.
• "DDS, p0180" (Drive Data Set, DDS count)
• "EDS, p0140" (Encoder Data Set, EDS count)
• "MDS, p0130" (Motor Data Set, MDS count)
• "PDS, p0120" (Power unit Data Set, PDS count)
Data sets can only be created and deleted when p0010 = 15.
Note
Information on the data sets can be taken from the following references:
Operating Instructions SINAMICS G120 Frequency Converter with CU240B-2 and CU240E-2
Control Units.
