Only typeB super-resistant (short-time delayed) universal current-sensitive residual current
devices are permitted for the Line Modules.
Table 6-1 Residual current devices that can be used with Line Modules
Abbreviation RCCB
Designations
• Residual current circuit breaker
• Residual current operated circuit breaker
• Ground-fault circuit interrupter
Rated current ≤80 A
Rated residual current 300mA
Recommendation Siemens SIQUENCE RCCB (residual current operated circuit
breaker), typeB, super-resistant [K], 300mA rated residual
current, series 5SV364.-4.
Suitable for Smart Line Modules 16...24kW
6.3.2.2 Operating conditions
Description
In case of unfavorable line supply conditions, as a result of the system that they are being used
in, converters can generate capacitive leakage currents that can cause residual current devices
to nuisance trip.
When using residual current devices to prevent leakage currents due to the operating conditions
causing residual current devices to trip, the following requirements apply:
• The residual current devices used must be typeB super-resistant (short-time delayed)
universal current-sensitive devices.
• The residual current device must have a rated residual current of 300mA.
• A separate residual current device must be used for each Line Module.
• It must be ensured that the loop impedance complies with local installation regulations.
• The total length of the shielded power cables (motor cables including line supply cable from
the line 󹪝lter to the connecting terminals of the Line Module) in the drive line-up must be less
than 350m.
• The system may be operated only with the recommended line 󹪝lters.
• Switching elements (disconnector unit, line contactors) for connecting and disconnecting
the drive system have a maximum 35ms delay time between closing or opening of the
individual main contacts.
