6.6.6 Technical data
Technical data
Table 6-6 Line reactors for Smart Line Modules
Feature Unit 6SL3100- 6SL5100-
0EE21-6AA0 0EE21-6AD0 0EE22-4AC0 0EE22-4AD0
Rated power kW 16 16 24 24
Power loss W 90 90 92 92
Weight kg 9.0 9.0 15.5 15.5
1)
Further, the same electrical rated values for the line reactors apply as for the assigned Smart Line Modules.
More information
The technical data of the Smart Line Modules are provided in Chapter "Technical data
(Page124)".
Line-side power components
6.6Line reactors
Booksize power units
Equipment Manual, 09/2023, A5E53307519B AA 111
