Description
Table 4-7 Maximum permissible total cable length according to the system design and EMC category in m
1)
Smart Line Module
Rated power
Line l‐
ter
Line re‐
actor
Category C2 Category C3 Limit values not complied with
16kW and 24kW - x - - 1000
16kW and 24kW x x 750 1000 -
1)
Cables must be shielded in order to comply with EMC limit values according to IEC61800-3.
4.12 Continuous current-carrying capacity and factors to reduce the
current for power and signal cables
4.12.1 Requirements for cable cross-sections
Requirement
WARNING
Overheating of power cables when permissible cross-sections are fallen below
Excessively thin power cables can result in overheating. This can result in severe injury or death
due to re and smoke.
• Only use power cables with suciently large cross-sections. Take into account the routing
type, ambient temperature and cable length.
• If smaller cross-sections are selected, you must ensure the appropriate level of conductor
protection in another way, e.g. by suitably setting closed-loop control parameters.
Description
Dimension cable cross-sections in compliance with local installation regulations.
Application planning
4.12Continuous current-carrying capacity and factors to reduce the current for power and signal cables
Booksize power units
Equipment Manual, 09/2023, A5E53307519B AA 57
