11.4.5.3 Connectable cable cross-sections
Description
Table 11-10 Conductor cross-sections of the cable for the DC link adapter 200A
Feature Cable cross-sections
Cable cross-sections Single core connection:
35...120mm
2
(AWG4...4/0)
Stripped length 27mm
11.4.5.4 Mounting the DC link adapter
Requirement
You can use the DC link adapter to supply one or several components. If you use the DC link
adapter to supply several components that are mounted directly adjacent to one another, then
the installation must meet the following requirements:
• The component line-up must be established to the left.
• The DC link adapter must be mounted onto the component at the far right.
Required tools:
• Slotted screwdriver 1.0x5.5mm to release the protective 󹪞ap
• Torx screwdriver TX20
• Torx screwdriver TX10 to fasten the DC link adapter
• Pliers for breaking out the cutout
