More information
To comply with product standards of plants and/or machines, when integrating the drive in
plants or machines, additional measures may be required. The additional measures are the
responsibility of the plant builder or machine OEM.
Disturbance-free operation of the drive is only guaranteed when specialist personnel carry
out the installation work in strict compliance with EMC regulations.
See also
Conguration Manual EMC Installation Guideline (https://
support.industry.siemens.com/cs/ww/en/view/60612658)
4.14.5
EMC in the 2nd environment (industrial areas)
4.14.5.1 The converter in the 2nd environment
WARNING
High-frequency interference
Dr
ives designed for the 2nd environment can cause high-frequency interference in a
residential environment. In cases such as these, supplementary interference suppression
measures are required.
4.14.5.2 Complying with Category C2 interference emission
Description
The drive meets the limit values of IEC61800‑3 Category C2 with regard to conducted and
radiated interference emissions under the following conditions:
• Operation on a TN or TT line system with a grounded neutral point
• Use of shielded motor cables
• Compliance with the maximum permissible total cable length
• Operation with the default pulse frequency or with reduced pulse frequency
• Using line
lters:
A separate line lter must be used for each converter.
When supplying converter components via the DC link adapter, it is not guaranteed that
limit values relating to radiated interference are maintained.
Compliance with the limit values for radiated interference is not guaranteed in operation
with synchronous motors and a Motor Module 200A with a pulse frequency of 16 kHz.
Application planning
4.14Electromagnetic compatibility (EMC)
Booksize power units
Equipment Manual, 09/2023, A5E53307519B AA 67
