Result
The line supply cable shield is secured to the optional additional Smart Line Module shield
connection plate using a shield connection clamp.
Figure7-18 Shield support with shield connection plate
7.13 Connect the protective conductor
Overview
There are two ways to connect the protective conductor to a Smart Line Module:
① Protective conductor connection at the power plug
② Protective conductor connection at the component
Figure7-19 Protective conductor connections at the Smart Line Module
How to connect the protective conductor to the Smart Line Module is explained below.
Smart Line Modules
7.13Connect the protective conductor
Booksize power units
140 Equipment Manual, 09/2023, A5E53307519B AA
