11.2.2 Dimension drawing
Dimension drawing
104,7 (4.12) 37,9 (1.49)
34,3 (1.35)
60,9 (2.40) 30,5 (1.20)
57,1 (2.25)
Figure11-1 Dimension drawing of the DRIVE-CLiQ coupling, all dimensions in mm and (inches)
