8.4 Motor Modules 45 A and 60 A
8.4.1 Interfaces and connections
8.4.1.1 Interfaces (front and upper side)
Overview diagram
;
;
;;;;
① X200 - X202: DRIVE-CLiQ interfaces
② X21: EP terminal/temperature sensor
③ Connection for the 24 V adapter (optional)
④ 24 V busbar
⑤ DC link busbars
⑥ Releasing the protective ap
Figure8-34 Interface overview, Motor Modules 45 A and 60 A (front and upper side)
