3. Cut out the detachable tabs at the motor connection block if the cables have a diameter
higher than 9.5mm (0.37inch).
4. Place the cable lug onto the threaded studs.
5. Screw the nuts onto the threaded studs and tighten them. Socket wrench size 10. Tightening
torque: 6Nm (53.1lbfin)
6. Close the motor connection block cover.
7. Insert the connector for the holding brake into interface X11 provided on the lower side of
the component.
8. When required, in the threaded socket M4 on the component, fasten a shield connection
clamp, type KLBUE 3-8 SC (Weidmüller), and connect the shield of the holding brake there.
8.4.11.5 Connecting the cable shield
Overview
You can fasten the shield of the motor connection cable to the shield connection plate of the
Motor Module using a hose clamp or a shield connection clamp.
Requirement
The following requirements must be satised:
• The motor connection cable is connected at the motor connection block.
• The shield connection plate is mounted.
• Use a suitable hose clamp or shield connection clamp.
Shield connection clamp Use Article number
Phoenix SK14 For shielded single cores with a conductor diame‐
ter of up to 14mm (0.55 inch)
8WH9130-0MA00
Phoenix SK35 For shielded cables with a cable diameter of up to
35mm (1.38inch)
8WH9130-0PA00
