Siemens SINAMICS S220

8.4.6 Characteristics
8.4.6.1 Rated duty cycle for C type Motor Modules
Duty cycle overview
The following rated duty cycles are applicable for operation with up to a maximum of 200%
overload.
t
I
I
n
10 s
0,25 s
I
max
Figure8-38 Duty cycle with initial load (for servo drives)
t
I
I
n
2,65 s
10 s
I
max
Figure8-39 Duty cycle without initial load (for servo drives)
4 min
10 min
0,7 I
n
I
S6
I
n
I
max
I
t
Figure8-40 S6 duty cycle with initial load with a duty cycle duration of 600s (for servo drives)
Motor Modules
8.4Motor Modules 45 A and 60 A
Booksize power units
196 Equipment Manual, 09/2023, A5E53307519B AA
