Siemens SINAMICS S220

Motor reactors Article
No.
6SE7031-5ES87-1FE0 6SE7031-8ES87-1FE0 6SE7032-6ES87-1FE0
Rated current [A] 85 132 200
d M6 M8 M8
Lengths n
1
and n
2
correspond to the distances between holes.
10.2.6 Technical data
10.2.6.1 Motor reactors for Motor Modules 3 ... 60 A
Technical data
Table 10-7 Motor reactors for Motor Modules 3...60A
Motor reactors Article No. Unit 6SE7021-0E
S87-1FE0
6SL3000-2
BE21-0AA0
6SE7022-6
ES87-1FE0
6SE7024-7
ES87-1FE0
6SE7027-2
ES87-1FE0
6SL3000-2
BE26-0AA0
Suitable for
Motor Module
Article No. 6SL5120-
 .UE13-0A..
.UE15-0A..
. UE21-0A . . . UE21-8A . . 1UE24-4A . .
1UE23-0A . .
1UE24-5A . . 1UE26-5A . .
Rated current A 5 9 18 30 45 60
Maximum current A 10 18 36 60 90 120
Power loss W 80 90 110 165 / 190 200 105
Maximum motor cable length
1 reactor
2 reactors
3 reactors

m

100
-
-

135
-
-

160
320
-

190
380
-

200
400
600
Cable connection  Screw terminals Flat connector for M8screw
Degree of protection  IP00
Weight kg 5.5 4.8 7.8 13 11 10.5
Mounting position  Any
Motor-side power components
10.2Motor reactors
Booksize power units
264 Equipment Manual, 09/2023, A5E53307519B AA
