NOTICE
Damage through use of incorrect DRIVE-CLiQ cables
Damage or malfunctions can occur on the devices or system when DRIVE-CLiQ cables are used
that are either incorrect or have not been approved for this purpose.
• Only use suitable DRIVE-CLiQ cables that have been approved by Siemens for the particular
application.
Note
Malfunctions due to polluted DRIVE-CLiQ interfaces
Malfunctions can occur in the system through the use of polluted DRIVE-CLiQ interfaces.
• Cover unused DRIVE-CLiQ interfaces with the supplied blanking covers.
7.3.2 Notes for UL applications
Description
Note
Overload protection for Smart Line Modules
The Smart Line Module has integrated overload protection according to UL61800-5-1.
Ensure that overload protection is active by following the instructions below:
• The protection threshold is 115% of the rated output current of the Smart Line Module.
• Using the appropriate conguration, ensure that if the Smart Line Module develops a fault
condition, a pulse inhibit is set for the Motor Modules connected to the DC link.
Smart Line Modules
7.3Safety instructions
Booksize power units
116 Equipment Manual, 09/2023, A5E53307519B AA
