Siemens SINAMICS S220

Motor reactors Article No. 6SE7027-2ES87-1FE0
Rated current [A] 45
d
2
7 (0.28)
Lengths n1, n2, n3 and n4 correspond to the distances between holes.
10.2.5.3 Dimension drawing, motor reactors 60A
Overview diagram
A
A
Figure10-5 Dimension drawing, motor reactors 60A
Table 10-5 Dimensions of motor reactors, all dimensions in mm and (inches)
Motor reactors Article No. 6SL3000-2BE26-0AA0
Rated current [A] 60
l
1
Max. 228(8.97)
I
2
267(10.51)
b
1
107(4.21)
b
max
125.5(4.94)
e 72(2.83)
h 220(8.66)
h
1
56(2.20)
h
2
100(3.93)
n
1
70(2.75)
n
2
176(6.92)
n
3
77(3.03)
n
4
249(9.80)
Motor-side power components
10.2Motor reactors
Booksize power units
262 Equipment Manual, 09/2023, A5E53307519B AA
