Siemens SINAMICS S220

10.2.5.2 Dimension drawing, motor reactors 45A
Overview diagram
H
$
Q
,
,
Q
Q
,
,
Q
$
E
G
G
Q
Q
$
+
K
Figure10-4 Dimension drawing, motor reactors 45A
Table 10-4 Dimensions of motor reactors, all dimensions in mm and (inches)
Motor reactors Article No. 6SE7027-2ES87-1FE0
Rated current [A] 45
I
1
219(8.62)
I
2
max. 182 (7.17)
b 119 (4.69)
H max. 180 (7.09)
h max. 165 (6.50)
e 58 (2.28) / terminal 4mm
2
72 (2.83)/ terminal 10mm
2
n
1
89(3.50)
n
2
201(7.91)
n
3
136 (5.35)
n
4
76 (2.99)
d M6
d
1
13 (0.51)
Motor-side power components
10.2Motor reactors
Booksize power units
Equipment Manual, 09/2023, A5E53307519B AA 261
