Siemens SINAMICS S220

Motor reactors Arti‐
cle No.
6SE7021-0ES87-1FE0 6SE7022-6ES87-1FE0 6SE7024-7ES87-1FE0
Rated current [A] 3
5
18 30
Figure ① ① ③
T 88 (3.46) 119(4.68) 104(4.09)
a - - 69(2.71)
h 146(5.74) 181(7.12) 103(4.05)
n
1
68(2.67) 89(3.50) 70(2.75)
n
2
166(6.53) 201(7.91) 176(6.92)
d M5 M6 M6
Lengths n
1
and n
2
correspond to the distances between holes.
Table 10-3 Dimensions of motor reactors, all dimensions in mm and (inches)
Motor reactors Article No. 6SL3000-2BE21-0AA0
Rated current [A] 9
Figure ②
I
1
150 (5.90)
I
2
178(7.00)
b
1
88 (3.46)
b
2
111(4.37)
b
max
67 (2.64)
e 159 (6.26)
n
1
64 (2.52)
n
2
113 (4.45)
n
3
68 (2.68)
n
4
166 (6.54)
d
1
5.8 (0.23)
d
2
11 (0.43)
d
3
M5
Lengths n1, n2, n3 and n4 correspond to the distances between holes.
Motor-side power components
10.2Motor reactors
Booksize power units
260 Equipment Manual, 09/2023, A5E53307519B AA
