Description
Line lters can optionally be used for Smart Line Modules in conjunction with the associated line
reactors. In conjunction with line reactors and a consequential EMC-compliant system design,
line lters limit the conducted electromagnetic emissions generated by the Line Modules to the
limit values according to IEC 61800-3. They are mainly eective in the frequency range from
9 kHz to 30 MHz; this is the range relevant to ensure compliance with the appropriate standard.
Table 6-2 Line lters for Smart Line Modules
Line lter Article number
16kW 6SL5100-0HE21-6DD0
24kW 6SL5100-0HE22-4DD0
6.5.2 Safety information
WARNING
Electric shock due to residual charges in power components
As a result of the capacitors, a hazardous voltage is present for up to 5 minutes after the power
supply has been switched o.
Contact with live parts can result in death or serious injury.
• Wait for 5 minutes before you check that the unit really is in a no-voltage condition and start
work.
WARNING
High leakage currents when the protective conductor in the line supply cable is
interrupted
The drive components conduct a high leakage current via the protective conductor. Touching
conductive parts when the protective conductor is interrupted can result in death or serious
injury.
• Adhere to the requirements for the dimensioning of the protective conductor set out in this
Equipment Manual.
CAUTION
Burns due to high surface temperatures
The surface of the components can reach high temperatures during operation. You can get
seriously burnt when touching the surface.
• Do not touch the component.
Line-side power components
6.5Line lter
Booksize power units
Equipment Manual, 09/2023, A5E53307519B AA 103
