8.4.5 Technical data
Technical data
Table 8-23 Single Motor Modules C type (45 A and 60A)
Feature Unit Article No. 6SL5120-
1UE24-5AC0 1UE26-0AC0
Output data
Rated current (l
rated
)
Intermittent duty current (l
s6
) 40%
Peak current (l
max
)

A
A
A

45
60
90

60
80
120
Output voltage3AC V 0 … 0.707 x DC link voltage
1)
(0 ... 480V at 680V DC)
Output frequency Hz 0 ... 550
2)
Apparent power for U
DC
of 600V
Rated power IEC
3)
Rated power NEC
4)
kVA
kW
hp
33
22
30
44
30
40
Input data
DC link voltage (U
DC
)
Overvoltage trip
Undervoltage trip
5)
Electronics power supply

V
V
V
V

495 … 720
820
380 … 432
24
DC link current (I
DC link
) A 56 75
DC link capacitance μF 1230 1410
Current-carrying capacity
DC link busbars
24 V DC busbars

A
A

200
20
Current consumption of the electronics
at 24VDC

A

1

1
Power loss W 344 462
Cooling air requirement m
3
/h 64 64
Weight kg 8.5 8.6
Cable lengths m See Chapter "Maximum permissible cable lengths (Page54)"
1)
In the case of overmodulation, a motor output voltage up to 3% higher is possible.
2)
Higher output frequencies up to a maximum of 3200Hz are possible with an additional license.
3)
Rated power of a typical standard induction motor at 3 AC 400V according to IEC 60947-4-1:2018 Annex G Table G.1
4)
Rated power of a standard induction motor at 3 AC 460 V according to NEC Table 430.250
5)
Depends on the parameterized device supply voltage
