7.12 Line connection
7.12.1 Connectable cable cross-sections
Description
Table 7-9 Conductor cross-sections and tightening torques
Rated power [kW] Line connection Cable cross-sections Tightening torque
16 - 24 Plug with screw connection
(6SL5166-2NA00-0AA0)
Finely stranded connection with:
6 ... 16mm
2
(AWG 6 ... 10)
1.2 - 1.5Nm (18lbf in)
Plug with push-in connection
(6SL5166-2NB00-0AA0)
-
7.12.2 Prepare the line supply cable
Overview
Smart Line Modules are connected to the line supply using a connection plug and a line supply
cable. To be able to connect the line supply cable to the connection plug, you must 󹪝rst prepare
it.
Requirement
NOTICE
Adherence to core and stripped lengths
If the speci󹪝ed core and stripped lengths are not complied with, single cores can be damaged
or shield contact prevented.
• Comply with the speci󹪝ed core and stripped lengths.
