5.4.2 Order data for the 24V terminal adapter
The 24 V terminal adapter can be ordered as replacement part.
X24: 24V terminal adapter
Article number Description
6SL3162-2AA00-0AA0 24 V terminal adapter for all Line Modules and Motor Modules in the booksize format
5.5 Connecting the 24 V busbars
5.5.1 Connecting the 24 V busbars
Overview
Die 24 V busbars of components lined up next to one another within a drive line-up are
connected using 24 V connectors. The 24 V connectors are included in the Terminal Kit of the
Motor Modules.
Requirement
WARNING
Electric shock if the cutout in the protective ap has been broken out
Live parts are exposed if the 24 V connectors are again removed at a later point in time.
Touching live components can result in death or severe injury.
• Replace the protective ap with the broken out cutouts with a new protective ap.
WARNING
Fire hazard for 24V connectors and unconnected DC link busbars
For drive lineups in series, whose DC link busbars are not connected with one another, it is not
permissible to insert 24 V connectors between these drive lineups. The 24 V connectors could
otherwise burn and cause severe injury or death as a result of re or smoke.
• If the DC link busbars of the components are not connected with one another, then you
must ensure that there is a separate 24 V supply for each component using a 24 V terminal
adapter.
Mounting
5.5Connecting the 24 V busbars
Booksize power units
