10.2.4 Interfaces and connections
Overview
Motor reactors with a rated current up to 18 A are equipped with terminals. Motor reactors for
Motor Modules with rated currents from 30...200A are connected using 󹪞at connectors.
Description
Article number Rated cur‐
rent [A]
Connecting terminals with cable
cross-sections
Tightening torque Protective con‐
ductor
6SE7021-0ES87-1FE0 3
5
Screw terminals 0.5-4mm
2
(AWG18...10)
0.5Nm (4.5lbfin) M6
6SL3000-2BE21-0AA0 9 Screw terminals 2.5-10mm
2
(AWG14...8)
2.5Nm (22lbfin)
6SE7022-6ES87-1FE0 18 Screw terminals 1.5-16mm
2
(AWG12...4)
1.2 Nm (11lbfin)
Article number Rated cur‐
rent [A]
Flat connector Tightening torque Protective con‐
ductor
6SE7024-7ES87-1FE0 30 M8 screw 13Nm (115lbfin) M6
6SE7027-2ES87-1FE0 45 M8 screw
6SL3000-2BE26-0AA0 60 M8 screw
6SE7031-5ES87-1FE0 85 M8 screw
6SE7031-8ES87-1FE0 132 M10 screw 25Nm (220lbfin)
6SE7032-6ES87-1FE0 200 M10 screw
Motor-side power components
10.2Motor reactors
Booksize power units
258 Equipment Manual, 09/2023, A5E53307519B AA
