7.14 Service and maintenance
7.14.1 Withdraw the connection plug
Procedure
Figure7-20 Release the connection plug
You have two options, if it should be necessary to withdraw the connection plug during
maintenance work:
Variant 1 (left image)
1. Using one hand, hold the connection plug at the front and back.
2. Release the plug using your other hand.
Variant 2 (right image)
Grasp the cable and release the connection plug using your thumb.
Smart Line Modules
7.14Service and maintenance
Booksize power units
142 Equipment Manual, 09/2023, A5E53307519B AA
